Steel
Platform
Fire Division Products
Specifications
Custom Chassis Choices
Arrow XT™, Dash® CF, Quantum® or Velocity®
Body Support Substructure
Pierce exclusive underslung steel body supports features a neoprene elastomer isolated mount system
Pump Range
Waterous, Hale, Darley Midship or PTO
Wind & Ice Ratings
Up to 50 mph winds & 1/4″ of ice
Basket
16 or 22 sq ft
Variations
85′ vertical, 78’1″ horizontal
100′ vertical, 93′ horizontal
PUC Availability
Yes
Tank
Up to 500 gallons
Stabilizers
2 sets of H-style: front & rear
Flow Capacity
3000 gpm
Hosebed Capacity
1000′ of 5″ hose
Payload Capacity
Up to 1000 lb
Body Warranty
10 yr
Structural Ladder Warranty
20 yr
